Frer T.K.A.K. Relay (A,AC Type) (Panel Type) 230VAC / 30mA–30A / 96x96mm.

Product Description: Ground Leakage Current Protection Relay, T-R 30 mA-30A, Type AC, A Panel Type (96×96)
Product Group: R X96DS
Product Code: R X96DSX025X21S

Current Adjustment Range: 30mA – 30A, with 3 different multipliers
Delay Adjustment Range: Instantaneous – 5 sec, with 2 different multipliers

Delay Accuracy: ±5% for the set value

Current Accuracy: ±5% for the set value
Operating Frequency: 45…65Hz
3rd Harmonic Filter: Attenuation 88% @ 150Hz

Operating Characteristic: Type A according to IEC775
Toroidal Connection Test: Continuous

Auxiliary Supply: 115/230Vac +/-10% 48…62Hz; / optional: 24, 48, 110, 220Vdc -10/+20%

Power Consumption: 3VA

Trip Contact: SPDT (1 output), 5A 250Vac

Operating Temperature: 0…+50°C, U.R. / R.H.

Storage Temperature: -20…+70°C

Insulation: 2kV 50Hz, 1 min.

Connections: Faston 6.35 x 0.8 mm

Thermoplastic Housing: UL94 V0

Housing Protection Class: IP40

Connection Protection Class: IP20

Relevant Standards: IEC 60947-2 Annex M ed. 8

Origin: IT
CE: CE symbol is shown in the image
Type: MRCD
Relay Type: AC A
Leakage Current Adjustment: Adjustable
Delay Type: Adjustable
Rated Residual Current Value: 30mA – 30A 300mA – 300A
Environmental Condition: Standard
